- Concealed Hinge, 180 Degree, For 14-26 Mm Panel Thickness
Concealed Hinge, 180 Degree, For 14-26 Mm Panel Thickness - Hafele
Product code: 341.05.500
£0.00
£7.02
(
£5.85
ex VAT)
Earn70
reward points
reward points
Please choose from the options below to show product code, price and availability
Bulk Buy Discounts for:
18-20mm
Quantity | Price (inc VAT) |
10 - 29 | £6.67 |
30 - 49 | £6.32 |
50 + | £5.62 |
Bulk Buy Discounts for:
14-16mm
Quantity | Price (inc VAT) |
10 - 39 | £8.02 |
40 + | £7.13 |
Bulk Buy Discounts for:
19-21mm
Quantity | Price (inc VAT) |
10 - 29 | £3.33 |
30 - 49 | £3.15 |
50 + | £2.80 |
Bulk Buy Discounts for:
24-26mm
Quantity | Price (inc VAT) |
10 - 29 | £14.70 |
30 + | £13.06 |
PRODUCT DETAILS
Material
SteelColour/finish
Brass platedArea of application
For concealed mountingDoor material
WoodOpening angle
180 ?Load bearing capacity per pair
8 kgInstallation
For screw fixing
