Unsprung Concealed Cup Hinge, 110 Degree Standard, For 14 - 22 Mm Thick Doors, Full Overlay, Hafele Metalla 310 - Hafele Metalla

Unsprung Concealed Cup Hinge, 110 Degree Standard, For 14 - 22 Mm Thick Doors, Full Overlay, Hafele Metalla 310 - Hafele Metalla

Product code: 311.60.924

£0.00
£0.82
(
£0.68
ex VAT)
Earn8
reward points
Please choose from the options below to show product code, price and availability
Out of stock. Purchase on backorder.
Add To Your Wishlist

Is the product you want unavailable? Enter your email below to be notified when it's back in stock!

Please note: this will not add you to our marketing list

  • PRODUCT DETAILS

    For wooden doors, Unsprung, screw fixing cup, 45/9.5, nickel plated

    Area of application:-For wooden doors

    Crank type:-Straight

    For door material:-Wood

    Material:-Steel

    Opening angle -110 degrees

    Cup drilling depth:-12.00 mm

    Cup drilling diameter :-35.00 mm

    Cup fixing:-for screw fixing

    Adjustment facility:-Side adjustment ±3 mm, Height adjustment ±2 mm (via mounting plate), Depth adjustment ±2 mm

    Installation:-Door to cabinet for quick fixing with SM quick fixing system

    Hafele Lifetime Guarantee:-25 years

    Can be used with the push to open mechanism- see in related products
