PRODUCT DETAILS

PLEASE NOTE Fixing clips are not included. Please see Related Products below

• Featuring revolutionary tool less 4D adjustment which gives vertical tilt, side to side and depth adjustment (ideal for perfect allignment and accurate gaps, for inframe and lay on applications)
• 100% fully synchronised runner giving silent, smooth operation throughout the movement of the drawer
• Improved soft close function - with liquid in damper to give continuous soft close
• 40 kg capacity as standard, so ideal for the majority of drawers, with 70 kg option available for very larger drawers
• Incredibly stable with the lowest deflection rates available
• Also available as add on push to open cartridge for handleless applications using soft close runner, Tipmatic cartridge and accessories
• For use with Vionara drawer system
• Please note: 250 mm length Dynapro runners are not compatible with Tipmatic

Nominal length
250 mm

Installation depth
253 mm

Load bearing capacity
40 kg

Material
Steel

Colour/finish
Zinc plated

Type of pull out
Full extension with Soft-Close soft and self closing mechanism

Adjustment facility
Height adjustment +3.5 mm
Side adjustment +/-1.5 mm
Tilt adjustment +4 mm
Depth adjustment +3.5 mm without tools using 4D clips

Installation
32 mm drilling pattern

Order reference
Front and rear 4D fixing clips, 433.19.090, or 3D fixing clips, 433.19.040, to be ordered separately depending on level of adjustment required
Varianta 5 mm countersunk screws, Hospa ?4.0 mm pan head screws and optional accessories to be ordered separately

Pack size
15 / 20 pairs
