Product code: 931.19.170

£0.00
£151.41
(
£126.18
ex VAT)
Earn1514
reward points
Please choose from the options below to show product code, price and availability
Out of stock. Purchase on backorder.
Add To Your Wishlist

Is the product you want unavailable? Enter your email below to be notified when it's back in stock!

Please note: this will not add you to our marketing list

  • PRODUCT DETAILS

    The GEZE ActiveStop has three functions which greatly enhance control and safety: Gentle stopping, silent closing and the ability to stop the door in the desired position to eliminate slamming doors
    Gentle stopping: Brakes the swing upon opening and stops the door in the desired position
    Silent closing: Prevents loud banging with soft silent closure, minimising risk of injury
    Keeps the door open to prevent it slamming without needing a separate door stop
    Holding position can be set individually using the adjustable opening angle

    Soft opening and soft closing mechanisms
    Holds the door conveniently open or pulls it gently into the lock
    Door stop not required
    Maintenance-free
    Arm: Mild steel

  • More Information

    Model :=ActiveStop

    For door material:-Wood

    Camber depth:-≤140 °

    For door weight:-≤45 kg

    Material:-Mechanism and guide rail: Aluminium
    Arm: Mild steel

    Colour/finish:-Silver coloured

    Mounting:-For DIN left and DIN right hand use

    Area of application:-For butting or rebated wooden interior doors, for concealed installation in door leaf

    Functioning principle

    Closing direction: Soft and self closing from approx. 25°,
    Opening direction: Soft opening and slow opening from approx. 60°,
    door is securely held in open position,
    Free swing range between 25° and 60°

    Adjustment facility:-Soft closing mechanism adjustable via valve

    For door width :-≤1,100 mm

    For door thickness :-≥38 mm

    Opening angle :80 – 140 °

    Supplied with



    1 ActiveStop soft and self closing system for doors
    1 guide rail with glide and end buffer
    1 connecting arm
    1 universal door latchbolt blocking device
    Mounting material
