Door Closer, Concealed Hydraulic, With Latch Action, Perko Powermatic - Hafele

Door Closer, Concealed Hydraulic, With Latch Action, Perko Powermatic - Hafele

Product code: 931.90.434

£0.00
£580.72
(
£483.93
ex VAT)
Earn5807
reward points
Please choose from the options below to show product code, price and availability
Out of stock. Purchase on backorder.
Add To Your Wishlist

Is the product you want unavailable? Enter your email below to be notified when it's back in stock!

Please note: this will not add you to our marketing list

  • PRODUCT DETAILS

    Unhanded
    Suitable for use on doors with arched heads where other types of closer are unsuitable
    Unit concealed within the door and frame, only the stainless steel links (grade 316) and face plates are visible
    Tested to 500,000 cycles, CE marked
    Closing speed and latching action are adjustable

    Certification:Conforms to BS EN 1154:1996/A1:2002
    Certifire No.: CF 370 30 mins
    Power size 3, 80 kg doors up to 950 mm wide
    Fire tested to BS EN 1634-1:2000 for 1 hour
    Opening forces comply with requirements of Approved Document M for doors of a minimum width of 826 mm whilst still conforming to BS EN 1154: 1997
    Exceeds the 65% efficiency recommendation for fire doors on accessible routes (80%)
    10 year guarantee


    Fire resistance

    Yes

    Colour/finish

    chrome plated, satin

    Area of application

    For flush doors only
    not suitable for rising or falling door hinges

    Closing force

    3 in accordance with EN 1154

    Forend material

    Brass

    For door height

    ≤2,100 mm

    For door width

    ≤950 mm

    For door weight

    ≤80 kg

    Opening angle

    ≤105 °

    Installation

    Distance between centres of the fixing plate must not exceed 52 mm in order to allow door to open through 105°

    Mounting

    DIN left/right

    Standard

    Certified in compliance with EN 1154:1996/A1:2002

    Grade

    3|8|3|1|1|3

    Order reference



    Buffer not supplied. Please order separately.

    Supplied with



    Full fixing instructions
    Fixing template
    Fixings
