PRODUCT DETAILS

Hafele Electric Free Flap Fittings

• An e-drive drive unit that is suitable for the Free flap 1.7 and Free flap 3.15 standard fittings
• Standard programming and operating functions for all Free E applications
• The installation position and the range of applications of the Free fittings remain unchanged
• The e-drive unit can be retrofitted at any time
• Extremely quiet and smooth running
• With integrated free-swing function for effortless manual operation of the flap (even in the event of a power failure)
• Automatic safety stop function with interruption of the opening or closing movement if obstacles are detected
• Parallel connection for up to three drive units, collision avoidance with cross-corner installation situations and temporary disabling of the drive to clean the flap fronts can also be programmed (optional)

E-drive for Free Fold, Free Up & Free Swing

• Installation: e-drive unit for screw fixing onto left Free fitting, push button sender for recess installation in side panel (drill hole 35 mm diameter)
• Nominal voltage: 24 V DC/2.5 A
• Radio frequency: 2.4 GHz
• Degree of protection: III
• Free e-drive covers the same application areas as the mechanical basic fittings. The drilling pattern on side panel and front panel also remain unchanged

Supplied with
1 e-drive drive unit
2 Push button senders (with CR2032 battery)
1 Drilling template for push button sender
1 Set of operating instructions
Fixing material

Zinc alloy drive housing, plastic push-button sender

Order driver, mains lead & cover cap set separately (see Related Products below)
