PRODUCT DETAILS

• The jig allows for an inset distance from the front carcase edge of 37 mm and from the back edge of 69 mm
• Integral sliding positioning tabs ensure consistent drilling locations
• An ideal addition to the other Unitool drilling jigs, for drilling series of holes in a line or groups of holes according to requirements
• Corresponds to 37 drill holes at intervals of 32 mm
• Suitable for series drilled holes, optionally with 3.5 mm diameter (8 mm and 10 mm diameter for dowel holes),
• Drilling distance from cabinet front edge 37 mm, 69 mm from cabinet rear edge, without turning the drilling jig due to stop plates
• Red anodized aluminium with non-slip coating
• 25 years Häfele Lifetime Guarantee

Order reference
Please order depth gauge and marking gauge separately.

Supplied with
1 Profiled aluminium rail
1 Surface drilling jig (L x W x H) 550 x 35 x 10 mm
8 Stop plates for 37 mm and 69 mm edge distances
2 Locating pins for ⌀ 3, 5 mm drill holes
