Parliament Butt Hinge, 102 X 152 X 5 Mm, Extruded Brass - Hafele

Parliament Butt Hinge, 102 X 152 X 5 Mm, Extruded Brass - Hafele

Product code: 921.08.614

£0.00
£118.12
(
£98.43
ex VAT)
Earn1181
reward points
Please choose from the options below to show product code, price and availability
Out of stock. Purchase on backorder.
Add To Your Wishlist

Is the product you want unavailable? Enter your email below to be notified when it's back in stock!

Please note: this will not add you to our marketing list

  • PRODUCT DETAILS

    • Brass pin

    Mounting
    For DIN left and DIN right hand use

    Door width max.
    1000 mm

    Flange shape
    square

    Material
    Brass

    Knuckle diameter
    13 mm

    Flange thickness
    5 mm

    Area of application
    Suitable for lightweight applications only*

    Max. door weight for 3 hinges
    35 kg

    Bearing type
    With fixed pin

    Supplied with
    Fixing screws

    *Additional information attributes

    Because of the short hinge knuckle this hinge can not sustain excessive loads or extra wide doors. If in doubt please consider extra wide projection hinges

    Pack size
    1 piece
