PRODUCT DETAILS

With switching function, Length x width x height 222 x 70 x 16 mm, Wattage 0 - 60 Watt.

For use with Loox5 or Loox5 compatible 12V lights

• With switching function
  Extremely flat, 16 mm
  12 V drivers with Loox5 generation plug system
  Max. recommended lead length from driver to switch: 6000 mm (leads not included)
  Not to be used/installed with a mains dimmable wall switch

Suitable for;-220–240 V AC: for Europe, Africa, Oceania, Asia (except Japan and Taiwan)

Mains voltage:-220 – 240 V

Mains frequency:-50 – 60 Hz

With switching function:-Yes

Version:-With overload protection

Output voltage:-12 V DC

Area of application :-LED (no other device)

Area of application :-For LED lights (not suitable for other devices)

Suitable for :-12 V consumer with Loox5 plug system

Material :-Plastic

Colour/finish ;-Black

Connected output ports :-6 x sockets, Loox5 2-pin 12 V

Control input ports :-1 x socket, Loox switch

Installation :-for glue fixing, Screw fixing

Installation note :-Provide for sufficient air supply and circulation at the mounting location. Provide inspection opening.

Efficiency at 230 V full load ;-88 %

Power consumption at 230 V no load :-0.50 W

Hafele Lifetime Guarantee :-7 years

Order reference

Loox mains leads must be ordered separately; e.g. 833.89.000

Supplied with

Fixings
