PRODUCT DETAILS

Junior 80/B system for wall pocket installation. Height adjustable.

• Application: For 1-leaf sliding doors for wall pocket installation
• Range:
  - Max. door weight 80 kg
  - Door width 700-1500 mm
  - Door thickness 40-50 mm
• Adjustment facility: Door height adjustable +3 mm, with integrated anti-twist protection, horizontal adjusting distance in lengthways direction in bayonet mount ±8 mm
• Version: Min. installation height, vibration transmission (structure-born sound) reduced by a separation layer between running track and fixing profile
• Installation: Suspension with recessed support and integrated suspension carriage, easy insertion of the door into the construction, clear threshold running installation in
  pre-mounted fixing profile using bayonet lock with insertion slope
• Disassembly: Running track up to 3 m can also be removed in fixed pocket constructions, this allows replacing or retrofitting individual components at any time
• Available with 20 mm longer bolt version which allows the track to be covered from below with removable ceiling elements
• Optional: Spring buffer for convenient ejection of the door
• Optional: Hawa-SoftMove 80 soft and self closing mechanism (SoftMove 80 cannot be used in combination with spring buffer)


• A second door stopper (941.80.300) is required when the soft and self closing mechanism and spring buffer are not being used
