Foot And Shaft Section, For Hafele Axilo 78 Plinth System - Single Unit Option - AXILO

Foot And Shaft Section, For Hafele Axilo 78 Plinth System - Single Unit Option - AXILO

Product code: 637.76.351s

£0.00
£1.22
(
£1.02
ex VAT)
View video
Earn12
reward points
Please choose from the options below to show product code, price and availability

Bulk Buy Discounts for:

150 mm (140-170 mm)

QuantityPrice (inc VAT)
100 +£1.07
Out of stock. Purchase on backorder.
Add To Your Wishlist

Is the product you want unavailable? Enter your email below to be notified when it's back in stock!

Please note: this will not add you to our marketing list

  • PRODUCT DETAILS

    Some of these are always stocked items, and are usually available for same day collection

    The Hafele Axilo 78™ system is easy, convenient and efficient.Compromising 6 unique components - the top section, the shaft and foot section, the plinth panel clip, the plinth panel holder, the adjusting tool and finally the extension tool.The system is a specially designed plinth fitting and adjustment tool to enable perfect alignment of cabinetry. Not only saving you time but most importantly allowing you to work without awkward postures; no more bending, crawling or stretching required to get to the back of the cabinets.Using the 6 components, the arm which serves as an extension tool can be used from any angle to slot into the bottom of the specially designed foot section so it can be adjusted higher or lower as required.Please watch the video linked to the left for a demonstration.

    Robust plinth system with large foot
    Easy plinth installation
    Height adjustment with different screw-in parts and tubes
    Easy adjustment of glides

    Height adjustment
    Adjustable at the side and from above -10 to +20 mm using AXILO 78 adjusting tool (scroll down to related products)

    Installation
    For plug fitting into top section

    Load bearing capacity
    150 kg per foot

    Material
    Plastic

    Colour
    Black
